Technical Data
Max. door weight: 150kg
Electric lock output: DC12V NO / NC
Working temperature: -20 ~ +50°C
Max. door width: 1200mm
Opening /Closing time: 6-125
Protection level: 1P68
Max. torque: 165Nm
Opening range: 86°- 95°
Unit size: 330 X116 X100 (mm)
Unit weight: 5.5kg
Power supply: AC220V#10%, 50/60Hz
Control box size: 215X205X60 (mm)
Installation method: ground embedding
Rated power: 55W
Running noise: <60dB
Standby power: <2W
• Features
The controller has display debugging interface, which is easy to operate and is equipped with various function ports such as electric lock and backup battery.
The BMC casing of the motor unit is injection Molded, DC motor is completely sealed for super waterproof, fire insulation, corrosion resistance.
The Max. load is 150KG, the optional DSW-3 unit can be opened 90 degrees or the DSW-3A unit can open the door 180 degrees (automatically sensing the passing direction of pedestrians, and opening the door with the pedestrian walking direction).
It is cold-resistant and high-temperature resistant and can work in -20°C-55°C environment.
Small size, waterproof, heavy load, easy construction, etc., can be used indoors and outdoors.
